NVIDIA · 2006
NVIDIA Quadro NVS 120M
The NVIDIA Quadro NVS 120M is a mobile professional graphics card released in 2006, based on the Curie architecture.
The NVIDIA Quadro NVS 120M is a mobile graphics card designed for professional use, released in June 2006. It is built on the Curie architecture with a G72GLM GPU chip manufactured on a 90 nm process. The card features 3 shading units, a base clock of 450 MHz, and 0.5 GB of DDR2 memory on a 64-bit bus, providing a memory bandwidth of 5.6 GB/s. It supports DirectX 9.0c and OpenGL 2.1, and connects via PCIe 1.0 x16. With a TDP of only 10 W, it is suitable for low-power mobile workstations.
Specifications
| Architecture unverified | Curie |
|---|---|
| GPU chip unverified | G72GLM |
| Process node unverified | 90 nm |
| Shading units unverified | 3 |
| Base clock unverified | 450 MHz |
| Memory size unverified | 0.5 GB |
| Memory type unverified | DDR2 |
| Memory bus unverified | 64 bit |
| Memory bandwidth unverified | 5.6 GB/s |
| Board power (TDP) unverified | 10 W |
| Bus interface unverified | PCIe 1.0 x16 |
| DirectX support unverified | 9.0c |
| OpenGL support unverified | 2.1 |
| Release date unverified | 2006-06-01 |
| Release year unverified | 2006 |
