NVIDIA Quadro NVS 110M
The NVIDIA Quadro NVS 110M is a mobile graphics card released in 2006, based on the Curie architecture with a G72M chip.
The NVIDIA Quadro NVS 110M is a mobile graphics card released on June 1, 2006. It is built on the Curie architecture using a G72M GPU chip fabricated on a 90 nm process. The card features 3 shading units, a base clock of 300 MHz, and 0.5 GB of DDR memory on a 64-bit bus, providing a memory bandwidth of 4.8 GB/s. It has a board power (TDP) of 10 W and connects via PCIe 1.0 x16. It supports DirectX 9.0c and OpenGL 2.1. The Quadro NVS 110M is designed for professional mobile workstations, offering basic 3D acceleration for CAD and visualization applications.
Specifications
| Architecture unverified | Curie |
|---|---|
| GPU chip unverified | G72M |
| Process node unverified | 90 nm |
| Shading units unverified | 3 |
| Base clock unverified | 300 MHz |
| Memory size unverified | 0.5 GB |
| Memory type unverified | DDR |
| Memory bus unverified | 64 bit |
| Memory bandwidth unverified | 4.8 GB/s |
| Board power (TDP) unverified | 10 W |
| Bus interface unverified | PCIe 1.0 x16 |
| DirectX support unverified | 9.0c |
| OpenGL support unverified | 2.1 |
| Release date unverified | 2006-06-01 |
| Release year unverified | 2006 |
