NVIDIA · 2014
NVIDIA GeForce 830M
The NVIDIA GeForce 830M is a mobile graphics card from 2014, based on the Maxwell architecture and GM108 chip.
The NVIDIA GeForce 830M is a mobile graphics card released on March 12, 2014. It is built on the Maxwell architecture using a 28 nm process node and features the GM108 GPU chip. The card has 256 shading units, a base and boost clock of 1029 MHz, and 2 GB of DDR3 memory on a 64-bit bus, resulting in a memory bandwidth of 14.4 GB/s. It supports DirectX 12, Vulkan 1.3, and OpenGL 4.5, and connects via PCIe 3.0 x16. The board power (TDP) is 25 W. The GeForce 830M is noted to have 50% of the performance of the GeForce 750 (Maxwell). It is designed for use in laptops and other mobile systems.
Benchmarks
| PassMark G3D Mark | 976 |
|---|---|
| PassMark G2D Mark | 136 |
| Geekbench 5 CUDA | 4,342 |
| Geekbench 5 OpenCL | 4,422 |
| Geekbench 5 Vulkan | 4,078 |
| Nero Score AVC encode | 415 fps |
Specifications
| Architecture unverified | Maxwell |
|---|---|
| GPU chip unverified | GM108 |
| Process node unverified | 28 nm |
| Shading units unverified | 256 |
| Base clock unverified | 1029 MHz |
| Boost clock unverified | 1029 MHz |
| Memory size unverified | 2 GB |
| Memory type unverified | DDR3 |
| Memory bus unverified | 64 bit |
| Memory bandwidth unverified | 14.4 GB/s |
| Board power (TDP) unverified | 25 W |
| Bus interface unverified | PCIe 3.0 x16 |
| DirectX support unverified | 12 |
| Vulkan support unverified | 1.3 |
| OpenGL support unverified | 4.5 |
| Release date unverified | 2014-03-12 |
| Release year unverified | 2014 |
| Notes unverified | 50% of 750 (Maxwell) |
