NVIDIA · 2011
NVIDIA GeForce GTX 560M
The NVIDIA GeForce GTX 560M is a mobile graphics card released in 2011, based on the Fermi architecture and GF116 chip.
The NVIDIA GeForce GTX 560M is a mobile graphics card released on May 30, 2011. It is built on the Fermi architecture using the GF116 GPU chip fabricated on a 40 nm process. The card features 192 shading units and a base clock of 775 MHz. It is equipped with 1.5 GB of GDDR5 memory on a 192-bit bus, providing a memory bandwidth of 60.0 GB/s. The card has a TDP of 75 W and connects via PCIe 2.0 x16. It supports DirectX 12.0 (11_0) and OpenGL 4.6, but does not support Vulkan. This GPU is designed for use in laptops and gaming notebooks from 2011.
Specifications
| Architecture unverified | Fermi |
|---|---|
| GPU chip unverified | GF116 |
| Process node unverified | 40 nm |
| Shading units unverified | 192 |
| Base clock unverified | 775 MHz |
| Memory size unverified | 1.5 GB |
| Memory type unverified | GDDR5 |
| Memory bus unverified | 192 bit |
| Memory bandwidth unverified | 60.0 GB/s |
| Board power (TDP) unverified | 75 W |
| Bus interface unverified | PCIe 2.0 x16 |
| DirectX support unverified | 12.0 (11_0) |
| Vulkan support unverified | N/a |
| OpenGL support unverified | 4.6 |
| Release date unverified | 2011-05-30 |
| Release year unverified | 2011 |
