NVIDIA GeForce GTX 760M
The NVIDIA GeForce GTX 760M is a mobile graphics card released in 2013, based on the Kepler architecture.
The NVIDIA GeForce GTX 760M is a mid-range mobile GPU introduced in May 2013. It uses the GK106 chip built on a 28 nm process, featuring 768 shading units. The core operates at a fixed 657 MHz with no boost clock. It is equipped with 2 GB of GDDR5 memory on a 128-bit bus, providing a memory bandwidth of 64.1 GB/s. The card has a TDP of 55 W and connects via PCIe 3.0 x16. It supports DirectX 12.0 (feature level 11_0), Vulkan 1.2, and OpenGL 4.6. This GPU is designed for laptops and pairs with Intel or AMD CPUs.
Specifications
| Architecture unverified | Kepler |
|---|---|
| GPU chip unverified | GK106 |
| Process node unverified | 28 nm |
| Shading units unverified | 768 |
| Base clock unverified | 657 MHz |
| Boost clock unverified | 657 MHz |
| Memory size unverified | 2 GB |
| Memory type unverified | GDDR5 |
| Memory bus unverified | 128 bit |
| Memory bandwidth unverified | 64.1 GB/s |
| Board power (TDP) unverified | 55 W |
| Bus interface unverified | PCIe 3.0 x16 |
| DirectX support unverified | 12.0 (11_0) |
| Vulkan support unverified | 1.2 |
| OpenGL support unverified | 4.6 |
| Release date unverified | 2013-05-30 |
| Release year unverified | 2013 |
