NVIDIA GeForce 845M
The NVIDIA GeForce 845M is a mobile graphics card released in 2015, based on the Maxwell architecture and built on a 28 nm process.
The NVIDIA GeForce 845M is a mobile graphics card released in 2015, targeting entry-level to mid-range laptops. It is based on the Maxwell architecture and uses the GM108 GPU chip fabricated on a 28 nm process. The card features 384 shading units, a base clock of 1071 MHz, and a boost clock of 1150 MHz. It is equipped with 2 GB of GDDR5 memory on a 64-bit bus, providing a memory bandwidth of 40 GB/s. The board power (TDP) is rated at 33 W, making it suitable for thin and light laptops. The card supports PCIe 3.0 x16 interface and includes DirectX 12, Vulkan 1.3, and OpenGL 4.5 support. It is typically paired with Intel or AMD processors in laptops.
Specifications
| Architecture unverified | Maxwell |
|---|---|
| GPU chip unverified | GM108 |
| Process node unverified | 28 nm |
| Shading units unverified | 384 |
| Base clock unverified | 1071 MHz |
| Boost clock unverified | 1150 MHz |
| Memory size unverified | 2 GB |
| Memory type unverified | GDDR5 |
| Memory bus unverified | 64 bit |
| Memory bandwidth unverified | 40 GB/s |
| Board power (TDP) unverified | 33 W |
| Bus interface unverified | PCIe 3.0 x16 |
| DirectX support unverified | 12 |
| Vulkan support unverified | 1.3 |
| OpenGL support unverified | 4.5 |
| Release date unverified | 2015-02-07 |
| Release year unverified | 2015 |
