ATI · 2007
Radeon X1550
The Radeon X1550 is a graphics card by ATI, released in 2007, based on the RV516 chip with 4 shading units and 512 MB DDR2 memory.
The Radeon X1550 is a graphics card by ATI, released on January 8, 2007. It is based on the Radeon X1000 architecture and uses the RV516 GPU chip manufactured on a 90 nm process. The card features 4 shading units, a base clock of 500 MHz, and 512 MB of DDR2 memory on a 128-bit bus, providing a memory bandwidth of 12.8 GB/s. It has a board power (TDP) of 27 W. The X1550 supports DirectX 9.0c and OpenGL 2.1. It was available in AGP 8x, PCI, and PCIe x16 bus interface versions.
Benchmarks
| PassMark G3D Mark | 61 |
|---|---|
| PassMark G2D Mark | 285 |
Specifications
| Architecture unverified | Radeon X1000 |
|---|---|
| GPU chip unverified | RV516 |
| Process node unverified | 90 nm |
| Shading units unverified | 4 |
| Base clock unverified | 500 MHz |
| Memory size unverified | 0.5 GB |
| Memory type unverified | DDR2 |
| Memory bus unverified | 128 bit |
| Memory bandwidth unverified | 12.8 GB/s |
| Board power (TDP) unverified | 27 W |
| Bus interface unverified | AGP 8x, PCI, PCIe x16 |
| DirectX support unverified | 9.0c |
| OpenGL support unverified | 2.1 |
| Release date unverified | 2007-01-08 |
| Release year unverified | 2007 |
