ATI · 2004
Radeon X800 Pro
The Radeon X800 Pro is a graphics card released by ATI in 2004, based on the R400 architecture and R420 GPU.
The Radeon X800 Pro is a graphics card from ATI, released on May 5, 2004. It is built on the R400 architecture using the R420 GPU on a 130 nm process node. The card features 12 shading units and a base clock of 475 MHz. It comes with 0.256 GB of GDDR3 memory on a 256-bit bus, providing a memory bandwidth of 28.8 GB/s. The board has a TDP of 49 W and uses an AGP 8× interface. It supports DirectX 9.0b and OpenGL 2.0. The Radeon X800 Pro was succeeded by the Radeon X850 Pro.
Specifications
| Architecture unverified | R400 |
|---|---|
| GPU chip unverified | R420 |
| Process node unverified | 130 nm |
| Shading units unverified | 12 |
| Base clock unverified | 475 MHz |
| Memory size unverified | 0.256 GB |
| Memory type unverified | GDDR3 |
| Memory bus unverified | 256 bit |
| Memory bandwidth unverified | 28.8 GB/s |
| Board power (TDP) unverified | 49 W |
| Bus interface unverified | AGP 8× |
| DirectX support unverified | 9.0b |
| OpenGL support unverified | 2.0 |
| Release date unverified | 2004-05-05 |
| Release year unverified | 2004 |
| Successor unverified | Radeon X850 Pro |
