ATI · 2004
Radeon X800 XL
The Radeon X800 XL is a graphics card by ATI, released in December 2004, based on the R400 architecture.
The Radeon X800 XL is a graphics card from ATI, released in December 2004. It uses the R400 architecture and the R430 GPU chip built on a 110 nm process. The card features 16 shading units and a base clock of 400 MHz. It has 0.256 GB of GDDR3 memory on a 256-bit bus, providing a memory bandwidth of 31.36 GB/s. The board has a TDP of 57 W and connects via PCIe ×16.
Specifications
| Architecture unverified | R400 |
|---|---|
| GPU chip unverified | R430 |
| Process node unverified | 110 nm |
| Shading units unverified | 16 |
| Base clock unverified | 400 MHz |
| Memory size unverified | 0.256 GB |
| Memory type unverified | GDDR3 |
| Memory bus unverified | 256 bit |
| Memory bandwidth unverified | 31.36 GB/s |
| Board power (TDP) unverified | 57 W |
| Bus interface unverified | PCIe ×16 |
| Release date unverified | 2004-12-01 |
| Release year unverified | 2004 |
