AMD · 2021
AMD Radeon Pro W6800X Duo
The AMD Radeon Pro W6800X Duo is a dual-GPU workstation graphics card released in 2021, featuring RDNA 2 architecture and 64 GB of GDDR6 memory.
The AMD Radeon Pro W6800X Duo is a professional graphics card designed for demanding workstation tasks. It is based on the RDNA 2 architecture and uses two Navi 21 GPU chips fabricated on a 7 nm process. The card features 7680 shading units and 120 ray tracing cores, with base and boost clocks of 1800 MHz and 1979 MHz respectively. It comes with 64 GB of GDDR6 memory on a 512-bit bus, providing a memory bandwidth of 1024 GB/s. The board power (TDP) is 400 W, and it connects via a PCIe 4.0 x16 interface. Display outputs include four Thunderbolt 3 ports and one HDMI 2.1 port. Released on August 3, 2021, this card is intended for use in high-end workstations for tasks such as 3D rendering, video editing, and scientific simulations.
Specifications
| Architecture unverified | RDNA 2 |
|---|---|
| GPU chip unverified | Navi 21 |
| Process node unverified | 7 nm |
| Shading units unverified | 7680 |
| Ray tracing cores unverified | 120 |
| Base clock unverified | 1800 MHz |
| Boost clock unverified | 1979 MHz |
| Memory size unverified | 64 GB |
| Memory type unverified | GDDR6 |
| Memory bus unverified | 512 bit |
| Memory bandwidth unverified | 1024 GB/s |
| Board power (TDP) unverified | 400 W |
| Bus interface unverified | PCIe 4.0 x16 |
| Display outputs unverified | 4× Thunderbolt 3, 1× HDMI 2.1 |
| Release date unverified | 2021-08-03 |
| Release year unverified | 2021 |
