AMD · 2021
AMD Radeon Pro W6800X
The AMD Radeon Pro W6800X is a professional graphics card released in 2021, based on the RDNA 2 architecture and Navi 21 GPU.
The AMD Radeon Pro W6800X is a professional graphics card released in August 2021. It is built on the RDNA 2 architecture with a Navi 21 GPU on a 7 nm process. The card features 3840 shading units and 60 ray tracing cores, with base and boost clocks of 1800 MHz and 2087 MHz respectively. It is equipped with 32 GB of GDDR6 memory on a 256-bit bus, providing a memory bandwidth of 512 GB/s. The board power (TDP) is 300 W, and it connects via PCIe 4.0 x16. Display outputs include four Thunderbolt 3 ports and one HDMI 2.1 port. This card is designed for professional workstations and is used with compatible motherboards and power supplies.
Specifications
| Architecture unverified | RDNA 2 |
|---|---|
| GPU chip unverified | Navi 21 |
| Process node unverified | 7 nm |
| Shading units unverified | 3840 |
| Ray tracing cores unverified | 60 |
| Base clock unverified | 1800 MHz |
| Boost clock unverified | 2087 MHz |
| Memory size unverified | 32 GB |
| Memory type unverified | GDDR6 |
| Memory bus unverified | 256 bit |
| Memory bandwidth unverified | 512 GB/s |
| Board power (TDP) unverified | 300 W |
| Bus interface unverified | PCIe 4.0 x16 |
| Display outputs unverified | 4× Thunderbolt 3, 1× HDMI 2.1 |
| Release date unverified | 2021-08-03 |
| Release year unverified | 2021 |
