NVIDIA · 2018
NVIDIA Quadro RTX 5000
The NVIDIA Quadro RTX 5000 is a professional graphics card released in 2018, based on the Turing architecture and featuring 16 GB GDDR6 memory.
The NVIDIA Quadro RTX 5000 is a professional graphics card released on August 13, 2018, with a launch MSRP of $2,299. It is based on the Turing architecture and uses the TU104-875-A1 GPU chip manufactured on a 12 nm process. The card features 3,072 shading units, 48 ray tracing cores, and 384 tensor cores, with base and boost clocks of 1,620 MHz and 1,815 MHz respectively. It has 16 GB of GDDR6 memory on a 256-bit bus, providing a memory bandwidth of 448 GB/s. The board power (TDP) ranges from 125 W to 230 W, and it requires one 6-pin and one 8-pin power connector. The card uses a PCIe 3.0 x16 bus interface and offers three DisplayPort outputs and one USB Type-C output. It supports DirectX 12.2, Vulkan 1.3, and OpenGL 4.6.
Specifications
| Architecture unverified | Turing |
|---|---|
| GPU chip unverified | TU104-875-A1 |
| Process node unverified | 12 nm |
| Shading units unverified | 3072 |
| Ray tracing cores unverified | 48 |
| Tensor / AI cores unverified | 384 |
| Base clock unverified | 1620 MHz |
| Boost clock unverified | 1815 MHz |
| Memory size unverified | 16 GB |
| Memory type unverified | GDDR6 |
| Memory bus unverified | 256 bit |
| Memory bandwidth unverified | 448 GB/s |
| Board power (TDP) unverified | 125-230 W |
| Power connectors unverified | 1x 6-pin + 1x 8-pin |
| Bus interface unverified | PCIe 3.0 x16 |
| Display outputs unverified | 3× DisplayPort, 1× USB Type-C |
| DirectX support unverified | 12.2 |
| Vulkan support unverified | 1.3 |
| OpenGL support unverified | 4.6 |
| Release date unverified | 2018-08-13 |
| Release year unverified | 2018 |
| Launch MSRP unverified | 2299 USD |
| Notes unverified | 3× DisplayPort 1× USB Type-C |
