NVIDIA · 2018
NVIDIA Quadro GV100
The NVIDIA Quadro GV100 is a professional graphics card for workstations, released in 2018. It features the Volta architecture with 5120 CUDA cores and 32 GB HBM2 memory.
The NVIDIA Quadro GV100 is a high-end workstation graphics card launched on March 27, 2018. It is based on the Volta architecture and uses the GV100 GPU chip manufactured on a 12 nm process. The card features 5120 shading units, 640 Tensor cores, and a base clock of 1132 MHz with a boost clock of 1627 MHz. It is equipped with 32 GB of HBM2 memory on a 4096-bit bus, providing a memory bandwidth of 870 GB/s. The board power (TDP) is 250 W, and it connects via PCIe 3.0 x16. Display outputs include 4× DisplayPort. It supports DirectX 12.1, Vulkan 1.3, and OpenGL 4.6. The card also supports NVLINK for multi-GPU configurations.
Specifications
| Architecture unverified | Volta |
|---|---|
| GPU chip unverified | GV100 |
| Process node unverified | 12 nm |
| Shading units unverified | 5120 |
| Tensor / AI cores unverified | 640 |
| Base clock unverified | 1132 MHz |
| Boost clock unverified | 1627 MHz |
| Memory size unverified | 32 GB |
| Memory type unverified | HBM2 |
| Memory bus unverified | 4096 bit |
| Memory bandwidth unverified | 870 GB/s |
| Board power (TDP) unverified | 250 W |
| Bus interface unverified | PCIe 3.0 x16 |
| Display outputs unverified | 4× DisplayPort |
| DirectX support unverified | 12.1 |
| Vulkan support unverified | 1.3 |
| OpenGL support unverified | 4.6 |
| Release date unverified | 2018-03-27 |
| Release year unverified | 2018 |
| Notes unverified | 4× DisplayPort, NVLINK support |
