Intel Core i5 14490F
The Intel Core i5 14490F is a 10-core desktop processor from the Raptor Lake microarchitecture, released in 2024.
The Intel Core i5 14490F is a desktop processor based on the Raptor Lake microarchitecture, manufactured on a 7 nm process node. It features 10 cores (6 performance-cores and 4 efficient-cores) and 16 threads, with a base clock of 2.8 GHz and a boost clock of 4.9 GHz. The processor includes 9.5 MB of L2 cache and 24 MB of L3 cache. It has a base power of 65 W and a maximum turbo power of 148 W. The CPU supports up to DDR5 4800 MT/s and DDR4 3200 MT/s memory across two channels, but does not support ECC memory. It has 20 PCIe lanes (version 5.0 and 4.0) and uses the FCLGA1700 socket. The processor lacks integrated graphics and has an unlocked multiplier. It supports instruction sets including SSE4.1, SSE4.2, and AVX2.
Specifications
| Microarchitecture unverified | Raptor Lake |
|---|---|
| Cores | 10 |
| P-cores | 6 |
| E-cores | 4 |
| Threads | 16 |
| Base clock | 2.8 GHz |
| Boost clock | 4.9 GHz |
| L2 cache (total) | 9.5 MB |
| L3 cache | 24 MB |
| Process node | 7 nm |
| TDP / base power | 65 W |
| Max turbo power | 148 W |
| Socket | FCLGA1700 |
| Memory support | Up to DDR5 4800 MT/s Up to DDR4 3200 MT/s |
| Memory channels | 2 |
| ECC memory support | No |
| Integrated graphics | None |
| PCIe lanes (CPU) | 20 |
| PCIe version | 5.0 and 4.0 |
| Instruction sets | Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2 |
| Unlocked multiplier | No |
| Release date | 2024-01-01 |
| Release year | 2024 |
