Intel · 2023
Intel Core i5 14600KF
The Intel Core i5 14600KF is a desktop processor from Intel's Raptor Lake family, released in October 2023.
The Intel Core i5 14600KF is a 14-core (6 P-cores + 8 E-cores) processor with 20 threads, based on the Raptor Lake microarchitecture. It has a base clock of 3.5 GHz and a boost clock of 5.3 GHz, with 20 MB of L2 cache and 24 MB of L3 cache. The processor is built on a 7 nm process node and has a TDP of 125 W, with a maximum turbo power of 181 W. It supports up to DDR5 5600 MT/s or DDR4 3200 MT/s memory across two channels, but does not support ECC memory. The CPU lacks integrated graphics and features 20 PCIe lanes (PCIe 5.0 and 4.0). It uses the FCLGA1700 socket and has an unlocked multiplier for overclocking. The launch MSRP was $294.
Benchmarks
| Blender Open Data score | 310.91 samples/min |
|---|---|
| Nero Score AI | 3,500 images/min |
| Nero Score AVC encode | 3,261 fps |
Specifications
| Microarchitecture unverified | Raptor Lake |
|---|---|
| Cores | 14 |
| P-cores | 6 |
| E-cores | 8 |
| Threads | 20 |
| Base clock | 3.5 GHz |
| Boost clock | 5.3 GHz |
| L2 cache (total) | 20 MB |
| L3 cache | 24 MB |
| Process node | 7 nm |
| TDP / base power | 125 W |
| Max turbo power | 181 W |
| Socket | FCLGA1700 |
| Memory support | Up to DDR5 5600 MT/s Up to DDR4 3200 MT/s |
| Memory channels | 2 |
| ECC memory support | No |
| Integrated graphics | None |
| PCIe lanes (CPU) | 20 |
| PCIe version | 5.0 and 4.0 |
| Instruction sets | Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2 |
| Unlocked multiplier | Yes |
| Release date | 2023-10-01 |
| Release year | 2023 |
| Launch MSRP | 294 USD |
