Intel Core i7 13790F
The Intel Core i7 13790F is a desktop processor from the Raptor Lake microarchitecture, released in 2023.
The Intel Core i7 13790F is a 16-core, 24-thread desktop processor based on the Raptor Lake microarchitecture, manufactured on a 7 nm process. It features 8 performance cores (P-cores) and 8 efficient cores (E-cores) with a base clock of 2.1 GHz and a boost clock of 5.2 GHz. The processor includes 24 MB of L2 cache and 33 MB of L3 cache. The 13790F has a base power of 65 W and a maximum turbo power of 219 W. It supports both DDR5-5600 and DDR4-3200 memory across two channels, but does not support ECC memory. It offers 20 PCIe lanes with support for PCIe 5.0 and 4.0. The processor lacks integrated graphics and has a locked multiplier, meaning it cannot be overclocked. It uses the FCLGA1700 socket and is compatible with Intel 600 and 700 series chipsets.
Specifications
| Microarchitecture unverified | Raptor Lake |
|---|---|
| Cores | 16 |
| P-cores | 8 |
| E-cores | 8 |
| Threads | 24 |
| Base clock | 2.1 GHz |
| Boost clock | 5.2 GHz |
| L2 cache (total) | 24 MB |
| L3 cache | 33 MB |
| Process node | 7 nm |
| TDP / base power | 65 W |
| Max turbo power | 219 W |
| Socket | FCLGA1700 |
| Memory support | Up to DDR5 5600 MT/s Up to DDR4 3200 MT/s |
| Memory channels | 2 |
| ECC memory support | No |
| Integrated graphics | None |
| PCIe lanes (CPU) | 20 |
| PCIe version | 5.0 and 4.0 |
| Instruction sets | Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2 |
| Unlocked multiplier | No |
| Release date | 2023-01-01 |
| Release year | 2023 |
