Intel · 2024
Intel Core i7 14700T
The Intel Core i7 14700T is a 2024 processor with 20 cores (8 P-cores, 12 E-cores) and 28 threads, based on Raptor Lake microarchitecture.
The Intel Core i7 14700T is a desktop processor released in 2024, built on the Raptor Lake microarchitecture and a 7 nm process node. It features 20 cores (8 performance-cores and 12 efficient-cores) and 28 threads, with a base clock of 1.3 GHz and a boost clock of 5.2 GHz. The processor includes 1600 KB of L1 cache, 28 MB of L2 cache, and 33 MB of L3 cache. It has a TDP of 35 W and a maximum turbo power of 106 W, and it is not unlocked for overclocking. The Core i7 14700T supports up to DDR5 5600 MT/s or DDR4 3200 MT/s memory across two channels, and it supports ECC memory. It integrates Intel UHD Graphics 770 and provides 20 PCIe lanes (PCIe 5.0 and 4.0). The processor uses the FCLGA1700 socket and is compatible with Intel 600 and 700 series chipsets. It supports instruction sets including 64-bit, Intel SSE4.1, SSE4.2, and AVX2.
Benchmarks
| Blender Open Data score | 227.58 samples/min |
|---|---|
| Nero Score AI | 2,862 images/min |
| Nero Score AVC encode | 2,533 fps |
Specifications
| Microarchitecture unverified | Raptor Lake |
|---|---|
| Cores | 20 |
| P-cores | 8 |
| E-cores | 12 |
| Threads | 28 |
| Base clock | 1.3 GHz |
| Boost clock | 5.2 GHz |
| L1 cache (total) unverified | 1600 KB |
| L2 cache (total) | 28 MB |
| L3 cache | 33 MB |
| Process node | 7 nm |
| TDP / base power | 35 W |
| Max turbo power | 106 W |
| Socket | FCLGA1700 |
| Memory support | Up to DDR5 5600 MT/s Up to DDR4 3200 MT/s |
| Memory channels | 2 |
| ECC memory support | Yes |
| Integrated graphics | Intel UHD Graphics 770 |
| PCIe lanes (CPU) | 20 |
| PCIe version | 5.0 and 4.0 |
| Instruction sets | 64-bit, Intel SSE4.1, Intel SSE4.2, Intel AVX2 |
| Unlocked multiplier | No |
| Release date | 2024-01-01 |
| Release year | 2024 |
| Launch MSRP | 384 USD |
